InnoFlex Bally Flexing Tester
Key Features
-
Advanced Servo Motor Control
Ensures precise positioning, stable testing, and automatic return to origin. -
Multi-Station Flexibility
12 workstations support single/multi-mode operation with independent cycle counting. -
Durable Construction
Precision mold-cast stainless steel body, Japanese NSK bearings, scratch-resistant finish. -
Quiet Operation
Noise level: 60 dB (lower than market alternatives). -
IoT-Ready
Integrates with SmarTexLab APP for ERP/LIMS connectivity and remote management.
Technical Specifications
| Parameter | Value |
|---|---|
| Power Supply | 220/110V, 50/60Hz |
| Weight | 55 kg |
| Testing Stations | 12 |
| Testing Speed | 100 cycles/min |
| Test Cycles | 0–9,999,999 (adjustable) |
| Max. Clamping Distance | 7 mm (sample thickness) |
| Upper/Lower Spacing | 8 mm (baseline distance) |
| Standard Accessories | Ø70×45 mm test cube |
Compliance Standards
| Standard | Type |
|---|---|
| ISO 5403-1:2017 | Standard |
| ISO 9210:2013 | Standard |
| ISO 20544:2011 | Standard |
| SATRA VTL 55 | Optional |
Smart Capabilities
-
Remote Monitoring (via SmarTexLab APP):
-
QR code sample scanning, automatic program selection.
-
Real-time test tracking, parameter adjustments, and completion alerts.
-
-
Data Security:
-
Auto-saves progress during power failures; editable run data.
-
-
Maintenance Support:
-
OTA updates, calibration reminders, consumable replacement alerts.
-
Key Advantages
-
Precision & Reliability:
-
Microprocessor-controlled servo motors ensure consistent flexing motion.
-
-
Efficiency:
-
Simultaneous testing of diverse samples across 12 stations.
-
-
User Safety:
-
Ergonomic interface; emergency stop function.
-
