ProPress Sample Press
Key Features
-
Fully Automated Cutting:
Punches and cuts samples (textiles, yarns, leather, plastics) into 5×5mm pieces in ≤8 seconds. Handles multiple fabric layers simultaneously. -
Precision & Consistency:
Ensures uniform sample size for reliable formaldehyde, pH, azo, and heavy metal testing. Eliminates manual cutting errors. -
Time Savings:
Reduces sample prep time by >80% (vs. 60+ seconds manually). -
Self-Cleaning System:
Air-blows fiber debris; built-in 2MP HD camera (1920×1080) prevents cross-sample contamination. -
Anti-Static Design:
Prevents sample adsorption during punching. -
Customizable Dies:
Supports shapes/sizes ≤80×80mm; die diameter: 4mm–113mm. -
Quiet Servo Drive:
No gas/oil pressure required; compact worktable fit.
Technical Specifications
| Parameter | Value |
|---|---|
| Power | 220V 5A / 110V 10A, 50/60Hz, 1200W |
| Net Weight | 100 kg |
| Gross Weight | 126 kg |
| Net Dimensions | 600 × 450 × 530 mm (L×W×H) |
| Packed Dimensions | 740 × 550 × 740 mm (L×W×H) |
| Press Thickness | 0.1–4 mm |
| Press Pressure | 1T, 2T, 3T, 4T, 5T (adjustable) |
Accessories & Consumables
| Component | Model/Size | Qty | Notes |
|---|---|---|---|
| Standard Matting | 4.M.011 (129×129×6 mm) | 6 pcs | Reversible |
| Standard Die | 2.Z.CV518.01 (5×5 mm) | 1 pc | Press area: 100×100 mm |
| Standard Pallet | 2.Z.CV518.03 (160×160×16 mm) | 2 pcs | |
| Optional Die | 2.Z.CV518.02 (3×3 mm) | 1 pc | Press area: 80×80 mm |
| Optional Hoover (220V) | 7.XCQ.001 (1200W) | 1 pc | |
| Optional Hoover (110V) | 7.XCQ.002 (1200W) | 1 pc | |
| Wear Parts (Matting) | 4.M.011 (129×129×6 mm) | – | Reversible |
| Wear Parts (Die) | 2.Z.CV518.01 (5×5 mm) | – | Custom sizes available |
Installation Requirements
-
Power: 220V or 110V socket.
-
Workspace: ≥700×1000 mm area.
-
Compressed Air: Optional (not required).
Applicable Tests & Standards
| Test | Standards |
|---|---|
| pH | ISO 3071, GB/T 7573 |
| Formaldehyde | ISO 14184.1, GB/T 2912.1 |
| Heavy Metals | GB/T 17593.1, GB/T 17593.2, GB/T 17593.3 |
| Azo Dyes | FZ/T 01133, GB/T 17592 |
Key Advantages
-
Process Integrity:
-
HD camera monitors cleaning to prevent sample mix-ups.
-
-
Versatility:
-
Custom dies for diverse materials (e.g., 3×3mm to 113mm diameter).
-
-
Efficiency:
-
Processes thick stacks (0.1–4mm) at 5T pressure.
-
-
Durability:
-
Adjustable pressure (1T–5T) extends cutter lifespan.
-
