TF171 Automatic Liquid Filling Machine
Description: The TF171 Automatic Liquid Filling Machine is designed for soaping color fastness tests, automatically refilling constant-temperature detergent into the designated test cup based on the sample weight and specified bath ratio. It features a sample weighing system, automatic heating, and a test cup induction device, integrating operations from weighing to liquid filling, improving accuracy and saving labor and time.
Specifications:
- Scale Range: 600 g, accuracy 0.01 g
- Soap Tank Volume: 5500 mL, working volume 5000 mL
- Single Pumping Volume of Soap: 2.5–300 mL, accuracy ≤ 100 mL ± 1 mL, > 100 mL ± 1%
- Pumping Speed: 28 mL/s
- Temperature Control Range: 0–65°C, accuracy ±1°C
- Steel Ball Filling Speed: 10 pcs/s
- Power Supply: 220V, 50/60 Hz, 6A, 1150W
- Weight: 48 kg
- Dimensions: 500 x 470 x 500 mm (L x W x H)
