TF310 45 Degree Flammability Tester
Description: The TF310 45 Degree Flammability Tester evaluates fabric flammability under controlled conditions, suitable for testing textiles, including medical textiles such as face masks, surgical gowns, protective clothing, and drapes. It features a stainless steel test cabinet with a glass observation panel, an automatic igniter for safe and easy operation, and automatic timing of flame spread in 0.1-second increments from ignition. A brushing device is included.
Specifications:
- Time Display and Accuracy: 0–999.9 s, 0.1 s
- Ignition Time: 1 ± 0.05 s
- Holder Dimensions: Outside 170 x 101 mm, Interior 152 x 38 mm
- Testing Chamber Size: 368 x 216 x 356 mm
- Nozzle-to-Specimen Distance: 8 mm, adjustable
- Flame Height: 16 mm, adjustable
- Sample Placement Angle: 45°
- Loading Weight: 30 g
- Specimen Size: 150 x 50 mm
- Power Supply: 220/110V, 50/60 Hz, 3A
- Gross Weight: 46 kg
- Dimensions: 610 x 490 x 710 mm (L x W x H)
Included Accessories:
- 1 Brushing Device
- 5 Sets of Sample Holders
- 16 mm Flame Gauge
- Sampling Plate
- 30 g Weight
Optional Accessories:
- Cotton Sewing Thread, No. 50, Mercerized
Standards:
- ASTM D1230
- 16 CFR-1610
- GB/T 14644
