TF513A/C/D Circular Sample Cutter
Description: The TF513 Circular Sample Cutter (GSM Cutter) cuts accurate fabric circular samples with smooth edges for various tests, such as GSM (100 cm²) and Martindale abrasion/pilling tests. It handles materials like fabric, thin films, tissue paper, corrugated cardboard, and synthetic leather, using a porous rubber cutting pad for safety.
Models:
- TF513A: Diameter 113 mm (100 cm²) – For European Fabric Yield System
- TF513C: Diameter 38 mm (12 cm²) – For Martindale Abrasion and Pilling Tester
- TF513D: Diameter 140 mm (154 cm²) – For Martindale Abrasion and Pilling Tester
Specifications:
- Gross Weight:
- TF513A: 2 kg
- TF513C: 1 kg
- Dimensions:
- TF513A: 190 x 190 x 150 mm (L x W x H)
- TF513C: 115 x 110 x 150 mm
