AirFicient Air Permeability Tester
Overview
-
Application: Tests air permeability of textiles, nonwovens, sponges, paper, and breathable products.
-
Key Advantages:
-
Simple operation: Select test standards/units on-screen.
-
Auto-recognition of test fixture head ranges.
-
Maintenance-free core components for reliable, repeatable results.
-
Self-designed calibration system (third-party validated).
-
Low noise, rapid results (seconds per test).
-
Trusted by: Canada Goose HQ & world’s #1 EV brand (automotive interiors).
-
Technical Specifications
| Parameter | Value |
|---|---|
| Power Supply | 220/110V, 50/60Hz |
| Weight | 125 kg |
| Dimensions (L×W×H) | 970 × 400 × 970 mm |
| Test Mode | Automatic |
| Standard Test Head | 20 cm² |
| Test Pressure | 10 ~ 2,500 Pa |
| Air Velocity | 0.6 ~ 10,000 mm/s (20 cm² head) |
| Sample Thickness Range | 0 ~ 10 mm (custom fixtures available) |
| Accuracy | < ±2% |
| Optional Test Heads | 5 cm², 25 cm² (5×5cm), 38.3 cm², 50 cm², 100 cm² |
| Measurement Units | mm/s, m/s, l/m²/s, ft³/min/ft², cfm, cm³/s/cm², l/s/cm², l/m²/min, l/dm²/min, l/min, m³/min, dm³/s, m³/s/m², m³/min/m², m³/h/m², ft³/s/ft² |
Compliance Standards
| Standard | Type |
|---|---|
| GB/T 5453 | Standard |
| ISO 9237 | Standard |
| ISO 9073:15 | Standard |
| JIS L1096 Item 8.26 Method C | Standard |
| BS 3424-16 | Standard |
| BS 6F 100 3.13 | Standard |
| NWSP 070.1.RO(15) | Standard |
| GB/T 24218.15 | Standard |
| ASTM D737 | Optional |
Smart Features
-
IoT Integration (SmarTexLab APP):
-
Direct ERP/LIMS connectivity via API.
-
QR code scanning for automatic sample identification.
-
Remote test monitoring/modification.
-
Digital records (process, results, temperature, humidity).
-
Real-time reports and OTA updates.
-
Calibration/maintenance alerts.
-
Online customer support (ChiuVention).
-
Key Benefits
-
Reliability:
-
Results consistent with third-party authorities.
-
Maintenance-free components ensure repeatability.
-
-
Efficiency:
-
Results in seconds; auto head recognition.
-
Low-noise operation.
-
-
Precision:
-
Self-calibrated system (third-party validated).
-
