HydroDetector Hydrostatic Head Tester
Overview
-
Tests waterproofness of textiles, leather, and films under high water pressure.
-
Fully automated with AI-powered visual detection (HD camera).
-
IoT-enabled for ERP/LIMS integration and remote control.
-
Noise-free operation (no compressed air required).
Technical Specifications
| Parameter | Value |
|---|---|
| Power Supply | 220/110V, 50/60Hz |
| Weight | 94 kg |
| Dimensions (L×W×H) | 360 × 670 × 635 mm |
| Standard Test Head | 100 cm² |
| Pressure Range | 0–600 kPa (higher customizable) |
| Pressure Units | Pa, kPa, mmHg, cm H₂O |
| Water Pressure Rise Rate | 1–60 kPa/min (adjustable) |
Key Features
-
AI-Powered Automation:
-
HD camera records tests; AI detects water droplets/test-end conditions.
-
Auto-stops tests and alerts via smartphone/buzzer.
-
OTA updates for continuous algorithm improvement.
-
-
Intelligent Assistance Mode:
-
Video playback for manual review and error correction.
-
-
Adaptive Clamping System:
-
Servo-driven clamps adjust force based on pressure to prevent leaks.
-
-
Servo-Mechanical Pressurization:
-
Stable pressure application at standard rates; prevents post-rupture spray.
-
-
User-Friendly Interface:
-
Smartphone-like control screen.
-
Export test videos/results in multiple formats.
-
Remote monitoring via IoT app.
-
Compliance Standards
| Standard | Type |
|---|---|
| AATCC 127 Option 2 | Standard |
| ISO 811 | Standard |
| GB/T 4744 | Standard |
| GB/T 40910 | Standard |
| JIS L1092 | Standard |
| ISO 9073-16 | Optional |
| EN 1734 | Optional |
| ISO 1420 | Optional |
| AATCC 208 | Optional |
| FZ/T 01004 | Optional |
Innovations
-
Noise Elimination:
Hydraulic system replaces compressed air. -
Rapid Fixture Replacement:
Quick-swap mesh clamps for efficient workflow. -
High-Pressure Customization:
Supports >600 kPa for specialized testing.
