TF135 Feather & Down Filling Power Tester
Description: The TF135 Feather & Down Filling Power Tester determines the filling power (massic volume) of feather and down materials. A platen applies pressure to the sample at a constant speed, and the height is measured after a stipulated time to calculate the massic volume based on the known diameter of the graduated cylinder.
Features:
- Automatic blowing system
- Individual filter system design
- DC gear motor driving
- SCM controlling
- Touchscreen operation
- Automatically lowers the platen and displays the height
- Equipped with a printer
Specifications:
- Measuring Speed: 520 ± 20 mm/min
- Measuring Height: 750 mm
- Measuring Accuracy: 0.1 mm
- Graduated Cylinder Internal Diameter: 289 ± 1 mm
- Plunger and Measuring Rod: Diameter 285 mm, Weight 94.3 g
- Air Velocity: 310 ± 50 L/min
- Power Supply: 220V, 50Hz, 750W
- Weight: 50 kg
- Dimensions: 880 x 740 x 1460 mm / 500 x 550 x 1200 mm (L x W x H)
Standards:
- GB/T 14272-2011
- GB/T 10288
- Optional Standard: BS EN 12130
