TF515 Pneumatic Sample Press
Description: The TF515 Pneumatic Sample Press is a desktop cutter for preparing samples for testing. It uses a 125 mm cylinder, cuts up to 10 mm depth, and supports a 125 x 125 mm table. At 100 psi, it produces 800 kg/f pressure and features double-bond security for safe operation. Custom cutting dies are available upon request.
Specifications:
- Cutting Area: 100 cm²
- Air Source: 0.5–0.6 MPa
- Power Supply: 220V, 50 Hz
- Gross Weight: 84 kg
- Dimensions: 590 x 490 x 830 mm (L x W x H)
